Detailed Product Description

48VLithium Battery for Solar panel
24v 200Ah Li-ion battery Bank for Solar Panel12v 120ah solar power system

12.8V 10Ah Lithium Battery for Solar panel

 24v 200Ah Li-ion battery Bank for Solar Panel
12v 120ah solar power system
12v 200ah solar power system

The Features of Lithium battery for Solar panel

1. Advanced design for deep cycle application
2. More than 2000times cycle use

3. High quality-to-cost rates.

4. Low self-discharge,Less than 3% per month

5. Fast charging,It can be charged 90% in 10 mins.

6. Operating Temprature:-40-+75 °C
7. Environmental

8. No exploding in fire. It is very safe.



The difference between our batter(New Li-ion Battery) and the tradional battery:

1. Small weight and size, Energy precision is more than 200Wh/Kg

2. Fast charging,It can be charged 90% in 10 mins.

3. So long life,more than 2000times cycle use

4. It can me used in different environment,-40-+75°C

5. No exploding in fire



 Sevice for our battery(Li-ion battery)

one year warranty for full replacement



The Specifications:

Model	XC-SP-001
Battery Material	LifePo4
Nominal Voltage	12V
Rated Capicaty	10Ah
Dimension	98*95*152(mm)
Internal Impedance	≤40mΩ
Max Charge Voltage	14.6V
Max Charge Current	10A
Rated Discharge Current	10A(0.2C)
Max Discharge Current	25A
Charging Mode	CC/CV
Pack Weight	About 1.5Kg
Over Current Protection	25A±3A
Cycle Life	1500 Cycles
Charge Temperature	0-45°C
Discharge Temperature	-20-55°C
